Technical Parameters

Max. static load N/mm²	250	Max. dynamic load N/mm²	140
Max. Speed（Dry） m/s	2	Max. Speed（Lubrication） m/s	>2
Max. PV(Dry) Short-term N/mm² · m/s	3.6	Max. PV(Dry) Continuos N/mm² · m/s	1.8
Temperature ℃	-195~+280	Friction Coefficient	0.03~0.20
Thermal Conductivity W（m·k）-1	42	Coefficient of Thermal Expansion	11x10-6k-1

Metallography & Characteristics

Note: Where the product can also choose a different base materials according to different conditions, such as: bronze substrate (HYB-11), a stainless steel substrate (HYB-60), and lead-free (HYB-13) and other formulations.

Application characteristics 1. The mixture of PTFE and lipophilic fibers forms a good transfer film to protect the grinding shaft during movement.
2. Good wear resistance and low friction coefficient.
3. Good performance, no biting.
4. Can be used in rotation, rocking, reciprocating motion.
5. Good corrosion resistance.
6. Because it does not contain lead, it can be used in green machinery such as food machinery and medical machinery.
7. Typical use: mainly used in medium acid, strong alkali occasions, such as: chemical acid and alkali flow meters, pumps, valves, printing and dyeing machinery, marine industry corrosion-resistant sliding parts.
